MSI B450M-A Pro Max – AM4 Motherboard
Original price was: ₨ 28,000.₨ 25,000Current price is: ₨ 25,000.
- Supports 3rd Gen AMD® Ryzen
- DDR4 Memory, up to 4133 (OC) MHz
- Running at PCI-E Gen3 x4
- Fully Digital Power Design
Description
The MSI B450M-A PRO MAX is an AMD AM4 motherboard inspired by architectural design. Optimized traces and isolated memory for improved memory performance. Convenient design elements like pin-header keep-out zones and smart SATA & USB locations. It provides a fully digital power design to support more cores and enhance performance. Fully optimized traces and isolated memory for improved memory performance.
| CHIPSET | AMD B450 |
|---|---|
| CPU | Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, 3000 G-Series, 2000 Series, 2000 G-Series and 1000 Series Desktop Processor and Athlon™ with Radeon™ Vega Graphics desktop processors Socket AM4 |
| MEMORY | 2x DDR4, Maximum Memory Capacity 64GB Memory Support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE) Supports Dual-Channel mode Supports non-ECC, UDIMM memory Supports ECC UDIMM memory (non-ECC mode) Supports un-buffered memory |
| AUDIO | Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
| STORAGE | 1x M.2 M.2_1 Source (From CPU) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| LAN | Realtek® 8125 2.5Gbps LAN controller |
| ONBOARD GRAPHICS | 1x HDMI™ Support HDMITM 2.0b, maximum resolution of 4K 60Hz* 1x DVI Support DVI-D, maximum resolution of 1920×1200 60Hz *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| SLOT | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 3.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 2.0 supports up to x1 (From Chipset) |
| RAID | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices |
| USB | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) |
| INTERNAL IO | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 1x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports |
| BACK PANEL PORTS |
|
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB INFO | mATX 200mmx236mm |
